PERFORMANCE
Processor AMD Ryzen™ Z2 Go (4C / 8T, 3.0 / 4.3GHz, 2MB L2 / 8MB L3)
Graphics Integrated AMD Radeon™ Graphics
Chipset AMD SoC Platform
Memory 16GB Soldered LPDDR5x-6400
Memory Slots Memory soldered to systemboard, no slots
Max Memory 16GB soldered memory, not upgradable
Storage 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Support One drive, up to 1TB M.2 2242 SSD
Storage Slot One M.2 2280 PCIe® 4.0 x4 slot
Card Reader microSD Card Reader
Optical None
Audio Chip High Definition (HD) Audio
Speakers Stereo speakers, 2W x2
Camera None
Microphone 2x, Array
Battery Integrated 55.5Wh
Power Adapter 65W USB-C® Slim (2-pin, Wall-mount)
Special Features Legion Coldfront cooling system
DESIGN
Display 8" WUXGA (1920x1200) IPS 500nits Glossy / Anti-fingerprint, 100% sRGB, 48-120Hz VRR, Panda King Glass, Low Blue Light, Touch
Touchscreen In-cell, 10-point Multi-touch
Touchpad Buttonless Mylar® surface touchpad (on the right controller), 10 x 10 mm (0.39 x 0.39 inches)
Case Color Glacier White
Surface Treatment Painting + Laser Special Texture
Case Material PC-ABS + 15% Talc
Pen Pen Not Supported
Controls A B X Y buttons D-pad Touchpad Left & right Joysticks 4x function buttons Y1 & Y2 buttons LT & RT buttons LB & RB buttons LT & RT button range switch
Dimensions (WxDxH) 298.5 x 127.55 x 22.6-43.4 mm (11.75 x 5.02 x 0.89-1.71 inches)
Weight Around 740 g (1.63 lbs)
Others • Power button
• Volume keys
SOFTWARE
Operating System Windows® 11 Home Single Language, Simplified Chinese / English
Bundled Software Office Trial
CONNECTIVITY
Ethernet No Onboard Ethernet
WLAN + Bluetooth AMD Wi-Fi® 6E RZ616, 11ax 2x2 + BT5.3
WWAN Non-WWAN
Standard Ports • 2x USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
• 1x Headphone / microphone combo jack (3.5mm)
• 1x Card reader
Docking Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for Legion Go S 8ARP1
SECURITY & PRIVACY
Security Chip Firmware TPM 2.0 Enabled
Fingerprint Reader None
SERVICE
Base Warranty 1-year, Courier or Carry-in
Included Upgrade 3Y Depot/CCI-IPENTRY (ESS)
