Product details of TP-Link EAP650 AX3000 Wireless Dual Band Multi-Gigabit Ceiling Mount - WiFi 6 , Dual Band , Access Point

- Ultra-Fast Wi-Fi 6 Speeds

: 574 Mbps simultaneous on 2.4 GHz and 2402 Mbps on 5 GHz total WiFi speeds of 2976 Mbps. †High Efficiency WiFi 6: More connected devices can enjoy faster speeds.Centralized cloud management: Omada SDN integration manages the entire network locally or from the cloud through the web UI or the Omada app.160 MHz channel: Double the data at peak transmission times on a single stream with HE160. ‡Seamless roaming: Video streams and voice calls are not affected as users roam between locations. §Omada Mesh: Enables WiFi connectivity between access points for extended range and flexible deployment. §PoE + Power: Supports 802.3at PoE + and DC power (adapter included) for flexible installations.Ultra-thin design: Φ160mm × 33.6mm sleek design brings more agility.

Interface    1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)

Bouton    Reset

Alimentation    • 802.3at PoE

• 12 V / 1.0 A DC (EU)

Consommation    • EU: 13.5 W

Dimensions (LxPxH)    160 × 160 × 33.6 mm

Type d'antenne    Internal Omni

• 2.4 GHz: 2× 4 dBi

• 5 GHz: 2× 5 dBi

Montage    • Ceiling /Wall Mounting (Kits included)

• Junction Box Mounting

CARACTÉRISTIQUES WIFI

Standards WiFi    IEEE 802.11ax/ac/n/g/b/a

Fréquence    2.4 GHz and 5 GHz

Débit du signal    • 5 GHz: Up to 2402 Mbps

• 2.4 GHz: Up to 574 Mbps

Fonctions WiFi    • 1024-QAM

• 4× Longer OFDM Symbol

• OFDMA

• Multiple SSIDs (Up to 16 SSIDs, 8 for each band)

• Enable/Disable Wireless Radio

• Automatic Channel Assignment

• Transmit Power Control (Adjust Transmit Power on dBm)

• QoS(WMM)

• MU-MIMO

• HE160 (160 MHz Bandwidth)‡

• Seamless Roaming §

• Omada Mesh§

• Band Steering

• Load Balance

• Airtime Fairness

• Beamforming

• Rate Limit

• Reboot Schedule

• Wireless Schedule

• Wireless Statistics based on SSID/AP/Client

Sécurité WiFi    • Captive Portal Authentication§

• Access Control

• Wireless Mac Address Filtering

• Wireless Isolation Between Clients

• SSID to VLAN Mapping

• Rogue AP Detection

• 802.1X Support

• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

Puissance de transmission    • CE:

<20 dBm(2.4 GHz, EIRP)

<23 dBm(5 GHz, Band1 & Band2, EIRP)

<30 dBm(5 GHz, Band3, EIRP)

• FCC:

<25 dBm (2.4 GHz)

<25 dBm (5 GHz)

ADMINISTRATION

Omada App    Yes

Administration Centralisée    • Omada Hardware Controller (OC300)

• Omada Hardware Controller (OC200)

• Omada Software Controller

• Omada Cloud-Based Controller

Accès Cloud    Yes (Through OC300, OC200, Omada Software Controller, or Omada Cloud-Based Controller)

Alertes Email    Yes

DEL ON/OFF    Yes

Administration de contrôle d'accès des adresses MAC    Yes

SNMP    v1, v2c, v3

Journal système local/distant    Local/Remote Syslog

SSH    Yes
